One-stop design for hardware and software, only for the storefront sign industry

Storefront sign industrial printer

Perfectly adapted to ChiTu storefront sign special pre-processing software, processing speed is faster

Cooperation with many storefront sign enterprises, with great development and a wealth of testing experience

Two kinds of chips freely choose (407/446)

Support network, SD card, thermocouple chip and other external devices as required configuration

F AD is specially designed for the storefront sign industry, with features such as fast printing, stable filament output and long working hours, and specific path and motion algorithm optimization for the large size printing scenarios of storefront signs.

Meanwhile, we have developed our own pre-processing software specifically for storefront sign printing, which can work with the mainboard to achieve a more efficient printing process, ultimately helping the implementation of 3D printing technology in the storefront sign industry.

Parameter

Size
160.00x105.00mm
Main chip
407/446
Input voltage/current
12-24V、10-25A
Motor driver chip
A4988(Z1、E1、E2)
Axis control
X (external), Y (external), Z1, Z2 (external), E1, E2
Heating port
3 channels (extrusion head 1, extrusion head 2, hot bed)
Temperature measurement port
3 channels (extrusion head 1, extrusion head 2, hot bed), support extrusion head 1, extrusion head 2 thermocouple temperature measurement
Leveling port
1 channel (limit switch), does not support BL Touch
Data port
U disk, SD card (optional)
Detect filament break port
1 channel (shared with leveling port)
Support network
Wired network port (optional)
Support host connection
USB Type-B
Support touch screen
2.8/3.5/4.3/5.0/7.0 inch TFT color touch screen
